In a mobile environment, you can move left and right to see the contents (tables).
| 电机 | 电压[V] | 电流[A] | 电阻[Ω] | 电感[mH] | 引线数量 | 机身长度[mm] |
|---|---|---|---|---|---|---|
| 17E2105 | 7.2 | 0.5 | 14.4 | 19.8 | 4 | 34.1 |
| 17E2110 | 3.8 | 1 | 3.8 | 5 | 4 | 34.1 |
| 17E2115 | 2.85 | 1.5 | 1.9 | 2.2 | 4 | 34.1 |
| 17E2205 | 11 | 0.5 | 22 | 46 | 4 | 48.1 |
| 17E2212 | 4.5 | 1.2 | 3.8 | 8 | 4 | 48.1 |
| 17E2225 | 2.5 | 2.5 | 1 | 1.8 | 4 | 48.1 |
In a mobile environment, you can move left and right to see the contents (tables).
| 丝杆直径 [inch] | 丝杆直径[mm] | 导程[inch] | 导程 [mm] | 导程代码 | 步长 @ 1.8° [mm] |
|---|---|---|---|---|---|
| 0.25 | 6.35 | 0.024 | 0.6096 | AA | 0.003048 |
| 0.25 | 6.35 | 0.0394 | 1 | AB | 0.005 |
| 0.25 | 6.35 |
0.025
|
0.635
|
A |
0.003175
|
| 0.25 | 6.35 | 0.048 | 1.2192 | B | 0.006096 |
| 0.25 | 6.35 | 0.05 | 1.27 | D | 0.00635 |
| 0.25 | 6.35 | 0.0625 | 1.5875 | F | 0.0079 |
| 0.25 | 6.35 | 0.096 | 2.4384 | J | 0.0122 |
| 0.25 | 6.35 | 0.1 | 2.54 | K | 0.0127 |
| 0.25 | 6.35 | 0.125 | 3.175 | L | 0.0159 |
| 0.25 | 6.35 | 0.192 | 4.8768 | Q | 0.024 |
| 0.25 | 6.35 | 0.2 | 5.08 | R | 0.0254 |
| 0.25 | 6.35 | 0.25 | 6.35 | S | 0.0318 |
| 0.25 | 6.35 | 0.333 | 8.4667 | U | 0.0423 |
| 0.25 | 6.35 | 0.384 | 9.7536 | W | 0.0488 |
| 0.25 | 6.35 | 0.5 | 12.7 | Y | 0.0635 |
| 0.25 | 6.35 | 1 | 25.4 | Z | 0.127 |
| 0.315 | 8 | 0.1575 | 4 | M | 0.02 |
| 0.315 | 8 | 0.315 | 8 | T | 0.04 |
| 0.315 | 8 | 0.0787 | 2 | G | 0.01 |
| 0.315 | 8 | 0.3937 | 10 | C | 0.05 |
In a mobile environment, you can move left and right to see the contents (tables).
|
尺寸A (mm) |
行程B (mm) |
重量(kg) | |
|---|---|---|---|
|
L=34.1
|
L=48.1
|
||
| 120 | 50 |
0.508
|
0.658
|
| 170 | 100 |
0.568
|
0.7
|
| 220 | 150 |
0.628
|
0.805
|
| 270 | 200 |
0.688
|
0.82
|
| 320 | 250 |
0.748
|
0.91 |
| 370 | 300 | 0.808 | 0.94 |
| 420 | 350 | 0.868 | 1 |
| 470 | 400 | 0.928 | 1.06 |
| 520 | 450 | 0.988 | 1.12 |
| 570 | 500 | 1.048 | 1.18 |
