In a mobile environment, you can move left and right to see the contents (tables).
| 电机类型 | 电机型号 | 适配编码器 | |
|---|---|---|---|
| 丝杆步进电机 | 贯通轴式 | 8N | EK1、KPL28 |
| 11N | EK1、EK2、KPL28、EK4C | ||
| 14N | EK2、KPL40、KPL56 | ||
| 17N | EK2、KPL40、KPL56、EK4C | ||
| 23N | EK2、EK3、KPL56、EK4C | ||
| 24N | EK2、EK3、KPL56 | ||
| 34N | EK3 | ||
| 外部驱动式 | 6E | EK6 | |
| 8E | EK1、KPL28 | ||
| 11E | EK1、EK2、KPL28、EK4C | ||
| 14E | EK1、EK2、KPL28 | ||
| 17E | EK1、EK2、EK4C、KPL40、KPL28 | ||
| 23E | EK2、KPL56、EK4C | ||
| 24E | EK2、KPL56 | ||
| 34E | EK3 | ||
| C型固定轴式 | 8C | EK1、KPL28 | |
| 11C | EK1、EK2、KPL28、EK4C | ||
| 14C | EK1、EK2、KPL28 | ||
| 17C | EK1、EK2、EK4C、KPL40、KPL28 | ||
| 23C | EK2、KPL56、EK4C | ||
| 24C | EK2、KPL56 | ||
| K型固定轴式 | 8K | EK1、KPL28 | |
| 11K | EK1、EK2、KPL28、EK4C | ||
| 14K | EK2、KPL40、KPL56 | ||
| 17K | EK2、KPL40、KPL56、EK4C | ||
| 23K | EK2、EK3、KPL56、EK4C | ||
| 24K | EK2、EK3、KPL56 | ||
| DLG 系列模组 | DLG28 | EK1、KPL28、EK4C | |
| DLG42 | EK2、EK4C、KPL40 | ||
| 空心轴步进电机 | 8HS | EK1、KPL28 | |
| 11HS | EK1、EK2、KPL28、EK4C | ||
| 14HS | EK2、KPL40、KPL56 | ||
| 17HS | EK2、KPL40、KPL56、EK4C | ||
| 23HS | EK2、EK3、KPL56、EK4C | ||
| 34HS | EK3 | ||
In a mobile environment, you can move left and right to see the contents (tables).
| 分 辨 率 [CPR] |
250 | 256 | 500 | 512 | 1000 | 1024 | 2000 | 2048 | 4000 | 4096 |
| 单端输出 | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
In a mobile environment, you can move left and right to see the contents (tables).
| 分辨率 [CPR] |
100 | 108 | 120 | 125 | 128 | 200 | 250 | 256 | 300 | 360 | 400 | 500 | 1000 | 512 | 720 | 800 |
| 单端输出 | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
| 差分输出 | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P |
In a mobile environment, you can move left and right to see the contents (tables).
| 分辨率 [CPR] | 50 | 100 | 192 | 200 | 250 | 256 | 360 | 400 | 500 | 720 | 900 | 1000 | 1250 | 2000 | 2500 | 4000 | 5000 |
| 单端输出 | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | ||||
| 差分输出 | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q |
In a mobile environment, you can move left and right to see the contents (tables).
| 分辨率 [CPR] | 64 | 100 | 200 | 500 | 1000 | 1800 | 2000 | 2500 | 3600 | 4000 | 5000 | 7200 | 8000 | 10000 |
| 单端输出 | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | |||||
| 差分输出 | A | B | C | D | E | F | G | H | I | J | K | L | M |
In a mobile environment, you can move left and right to see the contents (tables).
| 分辨率(CPR) | 625 | 800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3200 | 4000 |
| 单端输出 | - | - | - | - | - | - | - | - | - |
| 差分输出 | - | - | C | - | - | - | - | - | - |
In a mobile environment, you can move left and right to see the contents (tables).
| 型号 | 分辨率 | 代码 | 差分 | A | B | C | D | E | F | G | H | I | J |
| 单端 | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | |||
| KPL28 | - | - | - | 1000 | - | - | - | - | - | - | |||
| KPL40 | - | - | - | 1000 | - | - | - | - | - | - | |||
| KPL56 | - | - | - | 1000 | - | - | - | - | - | - | |||
